5 Best Digital Trim Gauges For Small Boat Dashboards That Maximize Every Inch

That tiny slice of fiberglass you call a dashboard is some of the most valuable real estate on your boat. Every square inch dedicated to a clunky, single-purpose analog gauge is an inch you can’t use for a phone mount, a cup holder, or a modern multi-function display. For small boat owners, optimizing the dash isn’t just about aesthetics; it’s about improving functionality, safety, and the overall enjoyment of your time on the water.

Disclosure: As an Amazon Associate, this site earns from qualifying purchases. Thank you!

Why Digital Gauges Maximize Small Dash Space

The single biggest advantage of a digital gauge is data density. One compact digital screen can display the information that used to require three or four separate analog dials. Instead of a dedicated trim gauge, a fuel gauge, and a voltmeter, you can have one unit that cycles through them all, or displays them simultaneously on a single, clean interface.

This consolidation is the core principle of small-space design: make every component do more than one job. A digital gauge isn’t just a gauge; it’s a data hub. This frees up precious dash space for other critical equipment like a GPS/fishfinder combo, VHF radio, or even just a bit of empty space to make the helm feel less cluttered and overwhelming.

Furthermore, digital displays offer superior readability. Forget trying to interpret a wavering needle in glaring sun or squinting at a poorly lit dial at dusk. A backlit LCD or LED screen provides a crisp, unambiguous readout in any light condition, which is a significant safety and convenience upgrade. The clean, modern look is just a bonus.

Faria KTF042: All-In-One Digital Solution

If you’re looking to replace a whole cluster of failing analog gauges with a single, elegant unit, the Faria KTF042 is a workhorse. Think of it as the Swiss Army knife for your dashboard. It typically combines a trim indicator with a fuel gauge, voltmeter, and sometimes even a tachometer or speedometer, all within a standard 4-inch cutout.

This gauge is perfect for the boater who wants a significant upgrade without the headache of a complex network installation. It’s a standalone system that wires directly to your existing senders, making it a relatively straightforward drop-in replacement project for a weekend. You get the benefits of a modern, multi-function display without needing to become a NMEA 2000 network engineer.

The real value here is immediate space reclamation. By installing one Faria unit, you might be able to remove three or four old gauges. This instantly frees up enough dash space to add a modern fishfinder or a panel with USB charging ports—a practical, high-impact upgrade for any small vessel.

KUS S5 Series: Compact and Accurate Readouts

Sometimes you don’t need an all-in-one command center. You just need a reliable, clear, and incredibly compact trim gauge to replace an old, fogged-up analog one. This is where the KUS S5 series shines. These gauges are typically built into the standard 52mm (2-1/16 inch) form factor, meaning they fit perfectly into the small holes common on older boat dashes.

The KUS philosophy is about doing one thing and doing it exceptionally well. The digital display provides a precise, easy-to-read trim level, often with a bar graph or a numerical percentage. There are no extra menus or functions to clutter the experience—just the critical information you need, presented clearly. This is ideal for tillers or small center consoles where every single inch is contested.

Their construction is another key selling point. With robust IP67 waterproof ratings, they are built to withstand spray, rain, and the general abuse of a marine environment. If your goal is a simple, bulletproof digital upgrade that fits into an existing small hole without any new cutting, a KUS gauge is a fantastic, no-fuss choice.

Veethree 781555: Multifunction Trim Display

The Veethree 781555 and similar models occupy a sweet spot between basic digital readouts and fully networked displays. They often pack multiple functions into a standard 2-inch gauge size, giving you more data without requiring a larger hole. You might get trim and volts, or trim and fuel, in a single compact unit.

What sets many Veethree gauges apart is their programmability. They are frequently designed to work with both American and European standard resistance senders, which you can select during setup. This versatility is a lifesaver, as it removes the guesswork of matching a new gauge to an old, unknown sender, a common headache in boat refits.

Think of this as the "smart" standalone gauge. It offers more data and flexibility than a basic digital model but doesn’t demand the commitment of a full NMEA 2000 network. For the boater who wants a modern, customizable look and a bit more information density in a small package, Veethree provides a powerful and practical solution.

Garmin GMI 20: The Ultimate Data Integrator

The Garmin GMI 20 isn’t just a gauge; it’s a window into your boat’s entire electronic nervous system. This is the choice for the boater who is building, or already has, a NMEA 2000 network. On its bright, high-contrast color screen, the GMI 20 can display virtually any data on that network: trim angle, engine RPM, fuel flow, depth, wind speed, GPS data, and dozens of other parameters.

The space-saving power here is immense. A single GMI 20 can be configured with multiple pages, allowing you to cycle through different data sets with the press of a button. One moment it’s your dedicated trim gauge; the next, it’s your fuel computer or depth sounder. This is the pinnacle of multifunctionality, allowing one 4-inch display to do the work of an entire dashboard of old analog gauges.

Of course, there’s a tradeoff. The GMI 20 is useless on its own; it requires a NMEA 2000 network and the appropriate sensors to feed it data. This means more initial cost and installation complexity. But if you’re already heading in that direction, it is without a doubt the most efficient and powerful way to display critical information in a minimal amount of space.

Livorsi Vantage View: Performance and Precision

Livorsi Marine has built its reputation in the high-performance boating world, and their Vantage View series reflects that. These gauges are designed for one thing above all else: instant, at-a-glance readability in the most demanding conditions. While they offer the precision of digital technology, the focus is on a bright, clear display that can be read without a second thought, even when bouncing across chop at high speed.

The design often incorporates ultra-bright LED indicators alongside a digital screen, giving you both a visual color-coded reference and a precise numerical value. This dual-display approach is a signature of performance-oriented design, where quick interpretation is a matter of safety and control. They combine a modern, high-tech feel with the intuitive nature of classic analog indicators.

While they can be integrated into larger systems, Livorsi gauges are for the boater who prioritizes clarity and durability over cramming the maximum number of functions into one screen. If your primary concern is an unwavering, sun-light-readable trim display that looks as good as it performs, the Vantage View series is a top-tier choice that brings a professional-grade feel to any dash.

Key Features for Compact Digital Trim Gauges

When you’re comparing options, it’s easy to get lost in the specs. From my experience, it boils down to four key considerations for a small dash. Get these right, and you’ll be happy with your choice.

• Connectivity: This is the first and most important decision. Is this a standalone gauge that wires directly to the trim sender, or is it a networked display (like NMEA 2000) that reads data from your engine’s network? The former is simpler and cheaper; the latter is more powerful and expandable but requires more infrastructure.
• Size and Footprint: Measure the existing holes in your dash. The easiest upgrade is a gauge that fits a hole you already have. Common sizes are 52mm (2-1/16") and 85mm (3-3/8"). Choosing a gauge that fits saves you from the nerve-wracking process of cutting new holes in your fiberglass.
• Readability: Don’t just look at features; consider the display itself. Is it a simple LCD or a bright, high-contrast color screen? Does it have adjustable backlighting for night use? A gauge you can’t read in direct sunlight is useless.
• Waterproofing: For a small boat, especially an open one, water intrusion is a constant threat. Look for a gauge with an IP67 rating or higher. This means it’s fully protected against dust and can be submerged in water up to one meter, ensuring it will survive spray, downpours, and washdowns.

Installation Tips for a Clean Dashboard Look

A clean installation is about more than just aesthetics; it’s about long-term reliability. The first rule is to make a template. Before you even think about drilling, trace your new gauge layout onto a piece of cardboard. Cut out the holes, place the cardboard over your dash, and see how everything fits. This simple step has saved me from countless costly mistakes.

When you do cut, use a high-quality hole saw for a perfect circle. To prevent the fiberglass gelcoat from chipping, apply painter’s tape over the area you’re about to drill and run your drill in reverse for the first few seconds to score the surface before drilling through. It’s a small trick that makes a huge difference in the finished look.

Finally, manage your wiring. Don’t just shove the excess wires behind the panel. Use zip ties or small cable clamps to bundle wires neatly and keep them away from sharp edges or moving parts behind the helm. A tidy wiring job not only looks professional but also makes future troubleshooting infinitely easier. This discipline is what separates a frustrating, unreliable setup from a clean, dependable one.

Ultimately, reclaiming your dashboard is about making smart, intentional choices. By replacing outdated analog dials with a compact, multifunction digital gauge, you’re not just modernizing your helm—you’re applying the core principle of small-space living to your boat. You’re making every inch work harder, creating a more functional, enjoyable, and safer space on the water.
